| Фотографии | Производитель. Часть # | Доступность | Цены | Количество | Таблицы данных | Packaging | Series | ProductStatus | NumberofChannels | Voltage-Isolation | CurrentTransferRatio(Min) | CurrentTransferRatio(Max) | TurnOn/TurnOffTime(Typ) | Rise/FallTime(Typ) | InputType | OutputType | Voltage-Output(Max) | Current-Output/Channel | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | VceSaturation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TIL186-1AC IN-DARLINGTON OUT OPTOCOUPLER |
13,096 | 0.51 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
6N139SLOGIC IC OUTPUT OPTOCOUPLER |
3,978 | 0.54 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 2500Vrms | 500% @ 1.6mA | - | 1.5µs, 7µs | - | DC | Darlington with Base | 18V | 60mA | 1.3V | 20 mA | - | -40°C ~ 85°C | Surface Mount |
|
TLP385(BLL,ETRANSISTOR OPTOCOUPLER; 4-PIN SO |
12,061 | 0.55 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 5000Vrms | 200% @ 5mA | 400% @ 5mA | 3µs, 3µs | 2µs, 3µs | DC | Transistor | 80V | 50mA | 1.25V | 50 mA | 300mV | -55°C ~ 110°C | Surface Mount |
|
TIL921AC IN-DARLINGTON OUT OPTOCOUPLER |
11,017 | 0.59 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
FOD2742AR2VTRANSISTOR OUTPUT OPTOCOUPLER |
2,930 | 0.59 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 | 2500Vrms | 100% @ 10mA | 200% @ 10mA | - | - | DC | Transistor | 70V | 50mA | 1.2V | - | 400mV | -25°C ~ 85°C | Surface Mount |
|
|
HCPL4502SDLOGIC IC OUTPUT OPTOCOUPLER |
2,134 | 0.60 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 | 2500Vrms | 19% @ 16mA | 50% @ 16mA | 450ns, 300ns | - | DC | Transistor with Base | 20V | 8mA | 1.45V | 25 mA | - | -55°C ~ 100°C | Surface Mount |
|
TIL918BDARLINGTON OUTPUT OPTOCOUPLER |
13,900 | 0.64 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
6N135VLOGIC IC OUTPUT OPTOCOUPLER |
2,987 | 0.73 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 | 2500Vrms | 7% @ 16mA | 50% @ 16mA | 450ns, 500ns | - | DC | Transistor with Base | 20V | 8mA | 1.45V | 25 mA | - | -55°C ~ 100°C | Through Hole |
|
|
6N139VLOGIC IC OUTPUT OPTOCOUPLER |
3,302 | 0.73 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 | 2500Vrms | 500% @ 1.6mA | - | 1.5µs, 7µs | - | DC | Darlington with Base | 18V | 60mA | 1.3V | 20 mA | - | -40°C ~ 85°C | Through Hole |
|
|
6N136VLOGIC IC OUTPUT OPTOCOUPLER |
870 | 0.73 |
RFQ |
Datasheet |
Bulk | - | Obsolete | 1 | 2500Vrms | 19% @ 16mA | 50% @ 16mA | 450ns, 500ns | - | DC | Transistor with Base | 20V | 8mA | 1.45V | 25 mA | - | -55°C ~ 100°C | Through Hole |
|
FODM1009OPTOISO 5KV 1CH TRANS LSOP4 |
11,451 | 0.73 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 5000Vrms | 200% @ 5mA | 400% @ 5mA | - | 5.7µs, 8.5µs | DC | Transistor | 70V | 50mA | 1.4V | 50 mA | 300mV | -40°C ~ 110°C | Surface Mount |
|
CNY171SVMOPTOISO 4.17KV TRANS W/BASE 6SMD |
10,554 | 0.75 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 4170Vrms | 40% @ 10mA | 80% @ 10mA | 2µs, 3µs | 4µs, 3.5µs (Max) | DC | Transistor with Base | 70V | 50mA | 1.35V | 60 mA | 400mV | -40°C ~ 100°C | Surface Mount |
|
|
FOD250LTLOGIC IC OUTPUT OPTOCOUPLER |
3,549 | 0.80 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 15% @ 16mA | 50% @ 16mA | 1µs, 1µs (Max) | - | DC | Transistor with Base | 7V | 8mA | 1.45V | 25 mA | - | -40°C ~ 85°C | Through Hole |
|
PS2561D-1Y-AOPTOISOLATOR 5KV TRANS 4DIP |
13,417 | 0.80 |
RFQ |
Datasheet |
Tube | NEPOC | Active | 1 | 5000Vrms | 50% @ 5mA | 400% @ 5mA | - | 3µs, 5µs | DC | Transistor | 80V | 50mA | 1.2V | 40 mA | 300mV | -55°C ~ 110°C | Through Hole |
|
|
FOD270LLOGIC IC OUTPUT OPTOCOUPLER |
3,839 | 0.81 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 5000Vrms | 400% @ 500µA | 7000% @ 500µA | 3µs, 50µs | - | DC | Darlington with Base | 7V | 60mA | 1.35V | 20 mA | - | -40°C ~ 85°C | Through Hole |
|
4N32VMOPTOISO 4.17KV DARL W/BASE 6DIP |
10,423 | 0.87 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 4170Vrms | 500% @ 10mA | - | 5µs, 100µs (Max) | - | DC | Darlington with Base | 30V | 150mA | 1.2V | 80 mA | 1V | -40°C ~ 100°C | Through Hole |
|
TIL919DARLINGTON OUTPUT OPTOCOUPLER |
11,867 | 0.90 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
HCPL0452LOGIC IC OUTPUT OPTOCOUPLER |
3,221 | 0.90 |
RFQ |
Datasheet |
Box | - | Obsolete | 1 | 2500Vrms | 19% @ 16mA | 50% @ 16mA | 450ns, 300ns | - | DC | Transistor | 20V | 8mA | 1.45V | 25 mA | - | -40°C ~ 85°C | Surface Mount |
|
|
CNY171VMOPTOISO 4.17KV TRANS W/BASE 6DIP |
13,067 | 0.92 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 4170Vrms | 40% @ 10mA | 80% @ 10mA | 2µs, 3µs | 4µs, 3.5µs (Max) | DC | Transistor with Base | 70V | 50mA | 1.35V | 60 mA | 400mV | -40°C ~ 100°C | Through Hole |
|
|
H11AV1AVMOPTOISO 4.17KV TRANS W/BASE 6DIP |
14,732 | 0.98 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 4170Vrms | 100% @ 10mA | 300% @ 10mA | 15µs, 15µs (Max) | - | DC | Transistor with Base | 70V | - | 1.18V | 60 mA | 400mV | -40°C ~ 100°C | Through Hole |
