Производитель. Часть #	Доступность	Цены	Количество	Таблицы данных	Packaging	Series	ProductStatus	LogicType	NumberofCircuits	NumberofInputs	Features	Voltage-Supply	Current-Quiescent(Max)	Current-OutputHighLow	LogicLevel-Low	LogicLevel-High	MaxPropagationDelay@VMaxCL	OperatingTemperature	MountingType
SN74LVC2G06QDCKRSV MOS LOGIC AUTOMOTIVE Texas Instruments	10,959	0.27	- + RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
ALVC04PWR MOS GENERAL PURP LOG Texas Instruments	10,987	0.27	- + RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
74LS10SCX NAND GATE, TTL National Semiconductor	12,058	0.27	- + RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
MM74HCT04SJ IC GATE XNOR 4CH 2-INP 14SOP Fairchild Semiconductor	12,331	0.27	- + RFQ	Datasheet	Bulk	74HCT	Active	XNOR (Exclusive NOR)	4	2	-	2V ~ 6V	2 µA	5.2mA, 5.2mA	0.8V	2V	20ns @ 6V, 50pF	-55°C ~ 125°C	Surface Mount
74AC14SJ INVERTER, AC SERIES, 6 FUNC, 1-I Fairchild Semiconductor	10,483	0.27	- + RFQ	Datasheet	Bulk	74AC	Active	Inverter	6	1	Schmitt Trigger	2V ~ 6V	2 µA	24mA, 24mA	0.5V ~ 1.1V	2.2V ~ 3.9V	10ns @ 5V, 50pF	-40°C ~ 85°C	Surface Mount
74F04SJX IC INVERTER 6CH 1-INP 14SOP Fairchild Semiconductor	32,869	0.27	- + RFQ	Datasheet	Bulk	74F	Obsolete	Inverter	6	1	-	4.5V ~ 5.5V	-	1mA, 20mA	0.8V	2V	5ns @ 5V, 50pF	0°C ~ 70°C	Surface Mount
NL27WZ00USH LOG DUAL 2 INPUT NAND onsemi	10,419	0.27	- + RFQ		Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
74F00PC IC GATE NAND 4CH 2-INP 14DIP Fairchild Semiconductor	29,375	0.27	- + RFQ	Datasheet	Tube	74F	Obsolete	NAND Gate	4	2	-	4.5V ~ 5.5V	-	1mA, 20mA	0.8V	2V	5ns @ 5V, 50pF	0°C ~ 70°C	Through Hole
74LS00PC NAND GATE, LS SERIES TTL National Semiconductor	10,647	0.27	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
DM74ALS00AN IC GATE NAND 4CH 2-INP 14DIP Fairchild Semiconductor	21,613	0.27	- + RFQ	Datasheet	Tube	74ALS	Obsolete	NAND Gate	4	2	-	4.5V ~ 5.5V	-	400µA, 8mA	0.8V	2V	11ns @ 5V, 50pF	0°C ~ 70°C	Through Hole
DM74ALS1004MX IC INVERTER 6CH 1-INP 14SOIC Fairchild Semiconductor	21,402	0.27	- + RFQ	Datasheet	Bulk	74ALS	Obsolete	Inverter	6	1	-	4.5V ~ 5.5V	-	15mA, 24mA	0.8V	2V	7ns @ 5V, 50pF	0°C ~ 70°C	Surface Mount
DM74ALS133MX IC GATE NAND 1CH 13-INP 16SOIC Fairchild Semiconductor	18,406	0.27	- + RFQ	Datasheet	Bulk	74ALS	Obsolete	NAND Gate	1	13	-	4.5V ~ 5.5V	-	400µA, 8mA	0.8V	2V	25ns @ 5V, 50pF	0°C ~ 70°C	Surface Mount
MM74HC32N IC GATE OR 4CH 2-INP 14DIP Fairchild Semiconductor	17,577	0.27	- + RFQ	Datasheet	Tube	74HC	Obsolete	OR Gate	4	2	-	2V ~ 6V	2 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	17ns @ 6V, 50pF	-40°C ~ 85°C	Through Hole
74AC00PC IC GATE NAND 4CH 2-INP 14DIP Fairchild Semiconductor	14,223	0.27	- + RFQ	Datasheet	Tube	74AC	Obsolete	NAND Gate	4	2	-	2V ~ 6V	2 µA	24mA, 24mA	0.9V ~ 1.65V	2.1V ~ 3.85V	8ns @ 5V, 50pF	-40°C ~ 85°C	Through Hole
MM74HCT32N IC GATE OR 4CH 2-INP 14DIP Fairchild Semiconductor	12,456	0.27	- + RFQ	Datasheet	Tube	74HCT	Obsolete	OR Gate	4	2	-	4.5V ~ 5.5V	2 µA	4.8mA, 4.8mA	0.8V	2V	20ns @ 5V, 15pF	-40°C ~ 85°C	Through Hole
DM74ALS1004N IC INVERTER 6CH 1-INP 14DIP Fairchild Semiconductor	11,000	0.27	- + RFQ	Datasheet	Tube	74ALS	Obsolete	Inverter	6	1	-	4.5V ~ 5.5V	-	15mA, 24mA	0.8V	2V	7ns @ 5V, 50pF	0°C ~ 70°C	Through Hole
74LS133PC NAND GATE, TTL, PDIP16 National Semiconductor	11,979	0.27	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
CD74HCT32E IC GATE OR 4CH 2-INP 14DIP Harris Corporation	10,528	0.27	- + RFQ	Datasheet	Tube	74HCT	Obsolete	OR Gate	4	2	-	4.5V ~ 5.5V	2 µA	4mA, 4mA	0.8V	2V	24ns @ 4.5V, 50pF	-55°C ~ 125°C	Through Hole
CD74HCT132E IC GATE NAND 4CH 2IN 14DIP Harris Corporation	9,138	0.27	- + RFQ	Datasheet	Tube	74HCT	Obsolete	NAND Gate	4	2	Schmitt Trigger	4.5V ~ 5.5V	2 µA	4mA, 4mA	0.5V ~ 0.6V	1.9V ~ 2.1V	33ns @ 4.5V, 50pF	-55°C ~ 125°C	Through Hole
74AC00SJX NAND GATE, AC SERIES, 4 FUNC, 2- Fairchild Semiconductor	12,953	0.28	- + RFQ	Datasheet	Bulk	74AC	Active	NAND Gate	4	2	-	2V ~ 6V	2 µA	24mA, 24mA	0.9V ~ 1.65V	2.1V ~ 3.85V	8ns @ 5V, 50pF	-40°C ~ 85°C	Surface Mount
