Производитель. Часть #	Доступность	Цены	Количество	Таблицы данных	Packaging	Series	ProductStatus	LogicType	NumberofCircuits	NumberofInputs	Features	Voltage-Supply	Current-Quiescent(Max)	Current-OutputHighLow	LogicLevel-Low	LogicLevel-High	MaxPropagationDelay@VMaxCL	OperatingTemperature	MountingType
74LVC2G00GN,115 IC GATE NAND 2CH 2-INP 8XSON NXP USA Inc.	14,216	0.18	- + RFQ	Datasheet	Bulk	74LVC	Active	NAND Gate	2	2	-	1.65V ~ 5.5V	4 µA	32mA, 32mA	0.7V ~ 0.8V	1.7V ~ 2V	3.3ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
74LVC2G00GN,115 NEXPERIA 74LVC2G00GN - NAND GATE NXP Semiconductors	14,005	0.18	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
74LVC132AD,112 NEXPERIA 74LVC132AD - NAND GATE Nexperia USA Inc.	553	73567.00	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-
MM74HCT05MTC IC INVERTER OD 6CH 1-INP 14TSSOP Fairchild Semiconductor	12,375	0.18	- + RFQ	Datasheet	Bulk	74HCT	Active	Inverter	6	1	Open Drain	4.5V ~ 5.5V	2 µA	-, 4.8mA	0.8V	2V	15ns @ 5V, 50pF	-40°C ~ 85°C	Surface Mount
74AUP2G86GT,115 NOW NEXPERIA 74AUP2G86GT - XOR G NXP USA Inc.	14,861	0.18	- + RFQ	Datasheet	Bulk	74AUP	Active	XOR (Exclusive OR)	2	2	-	0.8V ~ 3.6V	500 nA	4mA, 4mA	0.7V ~ 0.9V	1.6V ~ 2V	7.1ns @ 3.3V, 30pF	-40°C ~ 125°C	Surface Mount
MM74HC00MTC IC GATE NAND 4CH 2-INP 14TSSOP Fairchild Semiconductor	12,180	0.18	- + RFQ	Datasheet	Bulk	74HC	Active	NAND Gate	4	2	-	2V ~ 6V	2 µA	5.2mA, 5.2mA	0.5V ~ 1.8V	1.5V ~ 4.2V	15ns @ 6V, 50pF	-40°C ~ 85°C	Surface Mount
MM74HCT00MTC IC GATE NAND 4CH 2-INP 14TSSOP Fairchild Semiconductor	11,320	0.18	- + RFQ	Datasheet	Bulk	74HCT	Active	NAND Gate	4	2	-	2V ~ 6V	2 µA	5.2mA, 5.2mA	0.8V	2V	20ns @ 6V, 50pF	-55°C ~ 125°C	Surface Mount
HEF4030BT,652 NEXPERIA HEF4030BT - XOR GATE, 4 NXP Semiconductors	10,058	0.18	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
NC7SZ38FHX IC GATE NAND OD 1CH 2IN 6MICROPK Fairchild Semiconductor	11,331	0.18	- + RFQ	Datasheet	Bulk	7SZ	Active	NAND Gate	1	2	Open Drain	1.65V ~ 5.5V	2 µA	-, 32mA	-	-	4.3ns @ 5V, 50pF	-40°C ~ 85°C	Surface Mount
74AUP1G06GFH IC INVERTER OD 1CH 1-INP 6XSON NXP USA Inc.	11,483	0.18	- + RFQ	Datasheet	Bulk	74AUP	Active	Inverter	1	1	Open Drain	0.8V ~ 3.6V	500 nA	-, 4mA	0.7V ~ 0.9V	1.6V ~ 2V	10.5ns @ 3.3V, 30pF	-40°C ~ 125°C	Surface Mount
NX5P2553GVH NX5P2553 - BUFFER/INVERTER BASED NXP USA Inc.	13,421	0.19	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
MM74HCT08MTCX AND GATE, HCT SERIES, 4-FUNC, 2- Fairchild Semiconductor	12,655	0.19	- + RFQ	Datasheet	Bulk	74HCT	Active	AND Gate	4	2	-	4.5V ~ 5.5V	2 µA	4.8mA, 4.8mA	0.8V	2V	18ns @ 5V, 50pF	-40°C ~ 85°C	Surface Mount
74AUP1GU04GX,125 IC INVERTER 1CH 1-INP 5X2SON NXP USA Inc.	13,014	0.19	- + RFQ	Datasheet	Bulk	74AUP	Active	Inverter	1	1	-	0.8V ~ 3.6V	500 nA	4mA, 4mA	-	-	4.3ns @ 3.3V, 30pF	-40°C ~ 125°C	Surface Mount
XC7SHU04GV,125 IC INVERTER 1CH 1-INP SC74A NXP USA Inc.	12,104	0.19	- + RFQ	Datasheet	Bulk	7SHU	Active	Inverter	1	1	-	2V ~ 5.5V	1 µA	8mA, 8mA	0.3V ~ 1.1V	1.7V ~ 4.4V	7ns @ 5V, 50pF	-40°C ~ 125°C	Surface Mount
74AUP1G132GS,132 74AUP1G132 - LOW-POWER 2-INPUT N Nexperia USA Inc.	11,481	0.19	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
74AUP1GU04GX,125 NEXPERIA 74AUP1GU04GX - INVERTER Nexperia USA Inc.	11,090	0.19	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
74AUP1G386GS,132 NEXPERIA 74AUP1G386GS - XOR GATE Nexperia USA Inc.	11,010	0.19	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
74AUP2G14GN,132 NEXPERIA 74AUP2G14GN - INVERTER Nexperia USA Inc.	566	105000.00	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-
74AUP1G332GS,132 74AUP1G332 - LOW-POWER 3-INPUT O Nexperia USA Inc.	11,782	0.19	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
74AUP2G132GS,115 74AUP2G132 - LOW-POWER DUAL 2-IN Nexperia USA Inc.	10,879	0.19	- + RFQ	Datasheet	Bulk	*	Active	-	-	-	-	-	-	-	-	-	-	-	-
