Results:

Производитель. Часть #	Доступность	Количество	Таблицы данных	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
B66291P0000X187 FERRITE CORE I N87 1PC EPCOS - TDK Electronics	2,998	- + RFQ	Datasheet	Box	B66291	Obsolete	I	I 43 x 4 x 28	N87	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.161 (4.10mm)
B66293P0000X187 FERRITE CORE EPCOS - TDK Electronics	3,807	- + RFQ	Datasheet	Box	-	Obsolete	I	I 58 x 4 x 38	N87	-	8.4 µH	±25%	Ungapped	1450	2200	0.22	67.7	310	308	21000	Uncoated	0.160 (4.06mm)
B66295P0000X149 FERRITE CORE EPCOS - TDK Electronics	14,560	- + RFQ	Datasheet	Box	-	Active	-	-	N49	-	-	-	-	-	1500	0.13	69.7	519	518	36200	Uncoated	-
B66295P0000X187 FERRITE CORE EPCOS - TDK Electronics	10,514	- + RFQ	Datasheet	Box	-	Active	-	-	N87	-	-	-	-	-	2200	0.13	69.7	519	518	36200	Uncoated	-
B66307G300X127 FERRITE CORE EPCOS - TDK Electronics	13,891	- + RFQ	Datasheet	Box	-	Active	E	E 16 x 8 x 5	N27	-	-	-	-	-	2000	1.87	37.6	20.1	19.4	756	Uncoated	0.323 (8.20mm)
B66310GX187 FERRITE CORES EPCOS - TDK Electronics	12,912	- + RFQ		Box	B66310	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
B66310G0000X192 FERRITE CORES EPCOS - TDK Electronics	12,887	- + RFQ		Box	E20/10/11	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
B66311G0000X192 FERRITE CORE EPCOS - TDK Electronics	10,701	- + RFQ	Datasheet	Box	E20/10/6	Active	E	E 20 x 10 x 6	N92	-	-	-	-	-	1500	1.44	46.3	32.1	31.9	1490	Uncoated	0.398 (10.10mm)
B66317U0250E187 FERRITE CORE EPCOS - TDK Electronics	14,843	- + RFQ		Box	E25/13/7	Active	-	-	-	-	-	-	Gapped	-	-	-	-	-	-	-	-	-
B66341GX27 FERRITE CORES EPCOS - TDK Electronics	12,112	- + RFQ	Datasheet	Box	B66341	Active	EC	EC 52 x 24 x 14	N27	-	-	-	-	-	2000	0.58	105	180	141	18900	Uncoated	0.959 (24.35mm)
B66344G0200X187 FERRITE CORE EPCOS - TDK Electronics	11,034	- + RFQ	Datasheet	Box	E55/28/25	Active	E	E 55 x 28 x 25	N87	-	-	-	Gapped	-	2200	0.3	124	420	420	52100	Uncoated	1.094 (27.80mm)
B66358G0350X187 FERRITE CORE EPCOS - TDK Electronics	13,833	- + RFQ	Datasheet	Box	ETD29/16/10	Active	ETD	ETD 29 x 16 x 10	N87	-	-	-	Gapped	-	2200	0.93	70.4	76	71	5350	Uncoated	0.630 (16.00mm)
B66363G0600X127 FERRITE CORE EPCOS - TDK Electronics	11,066	- + RFQ	Datasheet	Box	ETD39/20/13	Active	ETD	ETD 39 x 20 x 13	N27	-	-	-	Gapped	-	2000	0.74	92.2	125	123	11500	Uncoated	0.787 (20.00mm)
B66367G0600X197 FERRITE CORE EPCOS - TDK Electronics	13,829	- + RFQ	Datasheet	Box	ETD49/25/16	Active	ETD	ETD 49 x 25 x 16	N97	-	-	-	Gapped	-	2300	0.54	114	211	209	24100	Uncoated	0.980 (24.90mm)
B66370GX172 FERRITE CORE EPCOS - TDK Electronics	10,947	- + RFQ	Datasheet	Box	-	Active	E	E 34 x 14 x 9	N72	-	2.7 µH	-20%, +30%	Ungapped	1770	2500	0.82	69.6	84.4	83.2	5900	Uncoated	0.577 (14.65mm)
B66370G0000X187 FERRITE CORE E N87 1PC EPCOS - TDK Electronics	13,249	- + RFQ	Datasheet	Box	E34/14/9	Active	E	E 34 x 14 x 9	N87	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.577 (14.65mm)
B66393G0000X187 FERRITE CORE E N87 1PC EPCOS - TDK Electronics	13,404	- + RFQ	Datasheet	Box	E16/6/5	Active	E	E 16 x 6 x 5	N87	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.228 (5.80mm)
B66393G0000X197 FERRITE CORE EPCOS - TDK Electronics	12,275	- + RFQ	Datasheet	Box	E16/6/5	Active	E	E 16 x 6 x 5	N97	-	1.25 µH	±25%	Ungapped	1480	2300	1.49	28.6	19.2	17.6	549	Uncoated	0.228 (5.80mm)
B66439G0000X187 FERRITE CORES EPCOS - TDK Electronics	11,163	- + RFQ		Box	EV25/13/13	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
B66453P0000X149 FERRITE CORE EPCOS - TDK Electronics	2,005	- + RFQ	Datasheet	Box	-	Obsolete	I	I 18 x 2 x 10	N49	-	2.1 µH	±25%	Ungapped	860	1500	0.51	20.3	39.5	38.9	802	Uncoated	0.079 (2.00mm)
