| Фотографии | Производитель. Часть # | Доступность | Цены | Количество | Таблицы данных | Packaging | Series | ProductStatus | Type | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Ratings | Applications | Features | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EEH-ZT1J560PCAP ALUM POLY HYB 56UF 63V SMD |
8,893 | 2.52 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZT | Active | Hybrid | 56 µF | ±20% | 63 V | 25mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 420 mA @ 100 Hz | 2.8 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEH-ZT1J330PCAP ALUM POLY HYB 33UF 63V SMD |
8,727 | 2.24 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZT | Active | Hybrid | 33 µF | ±20% | 63 V | 32mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 240 mA @ 100 Hz | 2.4 A @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
EEH-ZT1E331VCAP ALUM POLY HYB 330UF 25V SMD |
6,955 | 3.03 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZT | Active | Hybrid | 330 µF | ±20% | 25 V | 16mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 525 mA @ 100 Hz | 3.5 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.425 (10.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEH-ZT1H121PCAP ALUM POLY HYB 120UF 50V SMD |
12,764 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZT | Active | Hybrid | 120 µF | ±20% | 50 V | 23mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 435 mA @ 100 Hz | 2.9 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEH-ZT1J560VCAP ALUM POLY HYB 56UF 63V SMD |
8,597 | 3.03 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZT | Active | Hybrid | 56 µF | ±20% | 63 V | 25mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 420 mA @ 100 Hz | 2.8 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.425 (10.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
-Photo-Taped-Size-F.jpg)
|
EEH-AZC1J330BCAP ALUM POLY 33UF 20% 63V T/H |
10,354 | 0.00 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | ZC | Active | Hybrid | 33 µF | ±20% | 63 V | 40mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 110 mA @ 100 Hz | 1.1 A @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | - | Through Hole |
-Photo-Taped-Size-F.jpg)
|
EEH-AZA1K220BCAP ALUM POLY 22UF 20% 80V T/H |
13,477 | 0.00 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | ZA | Active | Hybrid | 22 µF | ±20% | 80 V | 45mOhm | 10000 Hrs @ 105°C | -55°C ~ 105°C | AEC-Q200 | Automotive | - | 155 mA @ 100 Hz | 1.55 A @ 100 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | - | Through Hole |
-Photo-Taped-Size-G.jpg)
|
EEH-AZC1V221BCAP ALUM POLY 220UF 20% 35V T/H |
11,322 | 0.00 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | ZC | Active | Hybrid | 220 µF | ±20% | 35 V | 20mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 300 mA @ 100 Hz | 2 A @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | - | Through Hole |
-Photo-Taped-Size-G.jpg)
|
EEH-AZT1J820BCAP ALUM POLY 82UF 20% 63V T/H |
11,182 | 0.00 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | ZT | Active | Hybrid | 82 µF | ±20% | 63 V | 25mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 420 mA @ 100 Hz | 2.8 A @ 100 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | - | Through Hole |
|
EEH-ZS1E471PCAP POLYMER HYBRID 470UF 25V SMD |
11,942 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZS | Active | Hybrid | 470 µF | ±20% | 25 V | 14mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 525 mA @ 100 Hz | 3.5 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.504 (12.80mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
EEH-ZC1E330RCAP ALUM POLY HYB 33UF 25V SMD |
11,165 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZC | Active | Hybrid | 33 µF | ±20% | 25 V | 80mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 55 mA @ 100 Hz | 550 mA @ 100 kHz | - | - | 0.197 Dia (5.00mm) | 0.240 (6.10mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
EEH-ZC1J330VCAP ALUM POLY 33UF 20% 63V SMD |
10,001 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZC, Anti-Vibration | Active | Hybrid | 33 µF | ±20% | 63 V | 40mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 110 mA @ 100 Hz | 1.1 A @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEH-ZC1J560VCAP ALUM POLY 56UF 20% 63V SMD |
11,511 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZC, Anti-Vibration | Active | Hybrid | 56 µF | ±20% | 63 V | 30mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 210 mA @ 100 Hz | 1.4 A @ 100 kHz | - | - | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EEH-ZC1K220VCAP ALUM POLY 22UF 20% 80V SMD |
12,551 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZC, Anti-Vibration | Active | Hybrid | 22 µF | ±20% | 80 V | 45mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 105 mA @ 100 Hz | 1.05 A @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
EEH-ZK1V330RCAP ALUM POLY 33UF 20% 35V SMD |
13,221 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZK | Active | Hybrid | 33 µF | ±20% | 35 V | 100mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 112.5 mA @ 100 Hz | 750 mA @ 100 kHz | - | - | 0.197 Dia (5.00mm) | 0.240 (6.10mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
EEH-ZA1E560VCAP ALUM POLY 56UF 20% 25V SMD |
13,454 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZA, Anti-Vibration | Active | Hybrid | 56 µF | ±20% | 25 V | 50mOhm | 10000 Hrs @ 105°C | -55°C ~ 105°C | AEC-Q200 | Automotive | - | 195 mA @ 100 Hz | 1.3 A @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.217 (5.50mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
EEH-ZA1V680XVCAP ALUM POLY 68UF 20% 35V SMD |
12,605 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZA, Anti-Vibration | Active | Hybrid | 68 µF | ±20% | 35 V | 35mOhm | 10000 Hrs @ 105°C | -55°C ~ 105°C | AEC-Q200 | Automotive | - | 300 mA @ 100 Hz | 2 A @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.315 (8.00mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
EEH-ZC1J470PCAP ALUM HYBRID 47UF 20% 63V SMD |
12,667 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZC | Active | Hybrid | 47 µF | ±20% | 63 V | 40mOhm | 4000 Hrs @ 125°C | -55°C ~ 125°C | AEC-Q200 | Automotive | - | 165 mA @ 100 Hz | 1.1 A @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
EEH-ZF1J330PCAP ALUM POLY HYB 33UF 63V SMD |
10,520 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZF | Active | Hybrid | 33 µF | ±20% | 63 V | 40mOhm | 1000 Hrs @ 150°C | -55°C ~ 150°C | AEC-Q200 | Automotive | - | 65 mA @ 100 Hz | 650 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.413 (10.50mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
EEH-ZF1E151VCAP ALUM POLY HYB 150UF 25V SMD |
14,601 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ZF, Anti-Vibration | Active | Hybrid | 150 µF | ±20% | 25 V | 27mOhm | 1000 Hrs @ 150°C | -55°C ~ 150°C | AEC-Q200 | Automotive | - | 120 mA @ 100 Hz | 800 mA @ 100 kHz | - | - | 0.315 Dia (8.00mm) | 0.425 (10.80mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
