Производитель. Часть #	Доступность	Цены	Количество	Таблицы данных	Packaging	Series	ProductStatus	Type	Applications	IntendedChipset	ChipsetManufacturer	Voltage-Primary	Voltage-Auxiliary	Voltage-Isolation	Inductance@Frequency	Frequency	OperatingTemperature	MountingType	Size/Dimension	Height-Seated(Max)	Footprint
VPH1-0190-R PULSE XFMR 27.4UH SMD Eaton - Electronics Division	8,364	5.79	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.508 L x 0.512 W (12.90mm x 13.00mm)	0.244 (6.20mm)	-
VP1-0190-R PULSE XFMR 12.2UH SMD Eaton - Electronics Division	9,331	5.78	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.508 L x 0.512 W (12.90mm x 13.00mm)	0.244 (6.20mm)	-
VP2-1600-R PULSE XFMR 78.4UH SMD Eaton - Electronics Division	7,521	8.90	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.642 L x 0.661 W (16.30mm x 16.80mm)	0.307 (7.80mm)	-
VP2-0216-R PULSE XFMR 10.6UH SMD Eaton - Electronics Division	6,755	9.55	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.642 L x 0.661 W (16.30mm x 16.80mm)	0.307 (7.80mm)	-
VP2-0116-R PULSE XFMR 5.7UH SMD Eaton - Electronics Division	7,827	9.65	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.642 L x 0.661 W (16.30mm x 16.80mm)	0.307 (7.80mm)	-
VPH2-0216-R PULSE XFMR 21.6UH SMD Eaton - Electronics Division	8,870	9.93	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.642 L x 0.661 W (16.30mm x 16.80mm)	0.307 (7.80mm)	-
VP5-0155-R PULSE XFMR 9.9UH SMD Eaton - Electronics Division	5,871	8.27	- + RFQ	Datasheet	Bulk	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.827 L x 1.122 W (21.00mm x 28.50mm)	0.425 (10.80mm)	-
VPH1-0076-R PULSE XFMR 10.9UH SMD Eaton - Electronics Division	8,559	7.81	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.508 L x 0.512 W (12.90mm x 13.00mm)	0.244 (6.20mm)	-
VPH1-0102-R PULSE XFMR 14.7UH SMD Eaton - Electronics Division	8,236	8.55	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.508 L x 0.512 W (12.90mm x 13.00mm)	0.244 (6.20mm)	-
VP1-0076-R PULSE XFMR 4.9UH SMD Eaton - Electronics Division	5,061	8.39	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.508 L x 0.512 W (12.90mm x 13.00mm)	0.244 (6.20mm)	-
VP1-0059-R PULSE XFMR 3.8UH SMD Eaton - Electronics Division	5,598	8.63	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.508 L x 0.512 W (12.90mm x 13.00mm)	0.244 (6.20mm)	-
VPH1-1400-R PULSE XFMR 201.6UH SMD Eaton - Electronics Division	7,809	8.63	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.508 L x 0.512 W (12.90mm x 13.00mm)	0.244 (6.20mm)	-
VPH2-1600-R PULSE XFMR 160UH SMD Eaton - Electronics Division	7,399	9.21	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.642 L x 0.661 W (16.30mm x 16.80mm)	0.307 (7.80mm)	-
VP2-0066-R PULSE XFMR 3.2UH SMD Eaton - Electronics Division	8,503	9.31	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.642 L x 0.661 W (16.30mm x 16.80mm)	0.307 (7.80mm)	-
VP5-0083-R PULSE XFMR 5.3UH SMD Eaton - Electronics Division	1,115	10.60	- + RFQ	Datasheet	Bulk	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.827 L x 1.122 W (21.00mm x 28.50mm)	0.425 (10.80mm)	-
VPH4-0075-R PULSE XFMR 12.7UH SMD Eaton - Electronics Division	1,918	11.12	- + RFQ	Datasheet	Bulk	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.709 L x 0.969 W (18.00mm x 24.60mm)	0.394 (10.00mm)	-
VPH5-0083-R PULSE XFMR 12UH SMD Eaton - Electronics Division	3,478	11.55	- + RFQ	Datasheet	Bulk	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.827 L x 1.122 W (21.00mm x 28.50mm)	0.425 (10.80mm)	-
VPH5-0155-R PULSE XFMR 22.3UH SMD Eaton - Electronics Division	1,853	10.60	- + RFQ	Datasheet	Bulk	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.827 L x 1.122 W (21.00mm x 28.50mm)	0.425 (10.80mm)	-
VP3-0055-R PULSE XFMR 4.5UH SMD Eaton - Electronics Division	8,979	8.36	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.673 L x 0.878 W (17.10mm x 22.30mm)	0.331 (8.40mm)	-
VPH3-0084-R PULSE XFMR 14.2UH SMD Eaton - Electronics Division	9,664	8.39	- + RFQ	Datasheet	Tape & Reel (TR),Cut Tape (CT)	VERSA-PAC®	Active	-	-	-	-	-	-	-	-	-	-40°C ~ 125°C	Surface Mount	0.673 L x 0.878 W (17.10mm x 22.30mm)	0.331 (8.40mm)	-
