Results:

Фотографии	Производитель. Часть #	Доступность	Цены	Количество	Таблицы данных	Packaging	Series	ProductStatus	FrequencyRange	Type	CurrentRating(Amps)	Inductance	ET(Volt-Time)	TurnsRatio-Primary:Secondary	CurrentRatio	DCResistance(DCR)	Ratings	MountingType	Size/Dimension	Height-Seated(Max)
	ACTL-0750-200 OPT C0.6 200A Split-Core Transformer Aim Dynamics	4,640	82.14	- + RFQ	Datasheet	Bag	Accu-CT®	Active	50/60Hz	Non-Invasive (Split Core)	200 A	-	-	100:1	-	-	-	Free Hanging (In-Line)	2.378 L x 0.902 W (60.40mm x 22.90mm)	2.402 (61.00mm)
	ACTL-0750-250 OPT C0.6 250A Split-Core Transformer Aim Dynamics	2,324	82.14	- + RFQ	Datasheet	Bag	Accu-CT®	Active	50/60Hz	Non-Invasive (Split Core)	250 A	-	-	100:1	-	-	-	Free Hanging (In-Line)	2.378 L x 0.902 W (60.40mm x 22.90mm)	2.402 (61.00mm)
	ACTL-0750-150 OPT C0.6 150A Split-Core Transformer Aim Dynamics	4,701	82.14	- + RFQ	Datasheet	Bag	Accu-CT®	Active	50/60Hz	Non-Invasive (Split Core)	150 A	-	-	100:1	-	-	-	Free Hanging (In-Line)	2.378 L x 0.902 W (60.40mm x 22.90mm)	2.402 (61.00mm)
	ACTL-0750-050 OPT C0.6 50A Split-Core Transformer Aim Dynamics	3,533	82.14	- + RFQ	Datasheet	Bag	Accu-CT®	Active	50/60Hz	Non-Invasive (Split Core)	50 A	-	-	100:1	-	-	-	Free Hanging (In-Line)	2.378 L x 0.902 W (60.40mm x 22.90mm)	2.402 (61.00mm)
	ACTL-0750-100 OPT C0.6 100A Split-Core Transformer Aim Dynamics	2,563	82.14	- + RFQ	Datasheet	Bag	Accu-CT®	Active	50/60Hz	Non-Invasive (Split Core)	100 A	-	-	100:1	-	-	-	Free Hanging (In-Line)	2.378 L x 0.902 W (60.40mm x 22.90mm)	2.402 (61.00mm)
	ACTL-1250-600 OPT C0.6 600A Split-Core Transformer Aim Dynamics	930	115.71	- + RFQ	Datasheet	Bag	Accu-CT®	Active	50/60Hz	Non-Invasive (Split Core)	600 A	-	-	100:1	-	-	-	Free Hanging (In-Line)	4.488 L x 1.583 W (114.00mm x 40.20mm)	3.283 (83.40mm)
	ACTL-1250-250 OPT C0.6 250A Split-Core Transformer Aim Dynamics	677	115.71	- + RFQ	Datasheet	Bag	Accu-CT®	Active	50/60Hz	Non-Invasive (Split Core)	250 A	-	-	100:1	-	-	-	Free Hanging (In-Line)	4.488 L x 1.583 W (114.00mm x 40.20mm)	3.283 (83.40mm)
	ACTL-0750-020 OPT C0.6 20A Split-Core Transformer Aim Dynamics	4,884	82.14	- + RFQ	Datasheet	Bag	Accu-CT®	Active	50/60Hz	Non-Invasive (Split Core)	20 A	-	-	100:1	-	-	-	Free Hanging (In-Line)	2.378 L x 0.902 W (60.40mm x 22.90mm)	2.402 (61.00mm)
	ACTL-1250-400 OPT C0.6 400A Split-Core Transformer Aim Dynamics	349	115.71	- + RFQ	Datasheet	Bag	Accu-CT®	Active	50/60Hz	Non-Invasive (Split Core)	400 A	-	-	100:1	-	-	-	Free Hanging (In-Line)	4.488 L x 1.583 W (114.00mm x 40.20mm)	3.283 (83.40mm)
